self-drilling screw/self-drilling screw/dovetail screw

self-drilling screw/self-drilling screw/dovetail screw

Self-Drilling Screw have a drill bit point that allows them to cut their own hole as they are driven into material. They are commonly used in metal and wood and eliminate the need for a pre-drilled hole, making them very efficient for certain applications.
Self-tapping screws do require a pre-drilled hole. They tap their own thread as they are driven into the material, making them useful for creating a strong hold in a variety of materials, including metal, plastic, and wood.

self-drilling screw/self-drilling screw/dovetail screw
PREV: No previous article NEXT:Metal Self-Tapping Lock Screws

This product can also be called a self-drilling screw, self-drilling screw, or dovetail screw. The implementation of the national standard is GB/T 15856.1-2002, German standard DIN7504N-1995, and Japanese standard JIS B 1124-2003. The screw has a tail tip like a twist drill, which can drill out of the center during assembly. The hole is then used to realize the self-tapping effect in the hole on the carrier by means of the adjacent threaded part.

Specification

 2.2-14

Length

 3-180mm

Material

 carbon steel

Head type

 hexagonal flange, countersunk head

Thread type

 self-tapping and self-drilling

Tensile strength

 450Mpa

Surface hardness

 ≥530HV

Core hardness

 320-400HV

Surface treatment

 color zinc, environmentally friendly blue and white zinc

Support non-standard customization
PTODUCT DESCRIPTION
Ningbo Risheng Fastener Co., Ltd.
About
Ningbo Risheng Fastener Co., Ltd.
Ningbo Risheng Fastener Co., Ltd.

As China self-drilling screw/self-drilling screw/dovetail screw Suppliers and Wholesale self-drilling screw/self-drilling screw/dovetail screw Manufacturers, Ningbo Risheng Fastener Co., Ltd. is a veteran fastener manufacturer founded in 1984, which can produce various types of self-tapping screws, machine screws, combination screws, triangle screws, stainless steel screws, hexagonal screws, anti-theft screws, and non-standard fasteners according to GB, JS ANSI, DIN, ISO, and other standards. in line with European ROHS environmental requirements.

At present, the company has nearly 22,000 square meters of R&D and production base, including a CNC machining center, mesh belt quenching furnace/tempering furnace high-speed cold block machine, combination screw washer, high-speed precision rolling machine, automatic tail collider, high-precision forming machine, four-mode four-power position machine and other production equipment. And projectors, torsion machine, tension machine, salt spray testing machine, screw screening machine, metallographic inlaying machine, Rockwell hardness machine, and other testing equipment.
