Cross Pan Head Self-Tapping Locking Screw

Cross Pan Head Self-Tapping Locking Screw

Cross Pan Head Self-Tapping Locking Screw is a type of fastener designed for specific applications where both the self-tapping and locking features are necessary. Have sharp, cutting threads that allow them to tap their own threads into softer materials like wood, plastic, or soft metals. The tip of the screw is typically sharp and pointed, facilitating the initial penetration and thread-forming process.

Considerations
Material Compatibility: Ensure the screw material is compatible with the material being fastened to prevent corrosion or damage.
Proper Installation: Follow recommended torque settings to avoid stripping the threads or damaging the material.

Cross Pan Head Self-Tapping Locking Screw
PREV: Metal Self-Tapping Lock Screws NEXT:Phillips Pan Head Tapping Screws With Pad And Point

Phillips pan head self-tapping locking screws have the characteristics of low screwing torque and high locking performance. At present, the standards and varieties of self-tapping locking screw fasteners in my country are GB/T6560 (cross-recessed pan head), GB/T6561 (cross-recessed countersunk head), GB/T6562 (cross-recessed countersunk head), GB/ Five series including T6563 (hexagonal head) and GB/T6564 (hexagonal flower-shaped cylindrical head).

Specification

 M2-M10

Length

 3-80mm

Material

 carbon steel

Head type

 Pan's head

Thread type

 self-tapping locking teeth

Slot type

 cross slot

Tensile strength

 450Mpa

Surface hardness

 ≥450HV

Core hardness

 270-390HV

Surface treatment

 environmentally friendly blue and white zinc
PTODUCT DESCRIPTION
Ningbo Risheng Fastener Co., Ltd.
About
Ningbo Risheng Fastener Co., Ltd.
Ningbo Risheng Fastener Co., Ltd.

As China Cross Pan Head Self-Tapping Locking Screw Suppliers and Wholesale Cross Pan Head Self-Tapping Locking Screw Manufacturers, Ningbo Risheng Fastener Co., Ltd. is a veteran fastener manufacturer founded in 1984, which can produce various types of self-tapping screws, machine screws, combination screws, triangle screws, stainless steel screws, hexagonal screws, anti-theft screws, and non-standard fasteners according to GB, JS ANSI, DIN, ISO, and other standards. in line with European ROHS environmental requirements.

At present, the company has nearly 22,000 square meters of R&D and production base, including a CNC machining center, mesh belt quenching furnace/tempering furnace high-speed cold block machine, combination screw washer, high-speed precision rolling machine, automatic tail collider, high-precision forming machine, four-mode four-power position machine and other production equipment. And projectors, torsion machine, tension machine, salt spray testing machine, screw screening machine, metallographic inlaying machine, Rockwell hardness machine, and other testing equipment.
